项     目 (Item) 数     据 (Data)
测试标准(Test standard)
产品间距(Pitch)                                      [mm] 5.00
极数(Poles) 2-3P
IEC测试数据(IEC Test data) /
额定电压(Rated voltage)                              [V] /
额定电流(Rated current)                              [A] /
额定连接容量(Rated connection capacity)(solid/stranded) [mm2] /
过压类别/污染等级/绝缘材料组别

(Surge voltage category/pollution degree/material group)

/
额定冲击电压(Rated impulse voltage)                    [KV] /
额定扭矩(Rated torque)                               [N.m] /
UL测试数据(ULTest data) /
应用组别(Use group) B C D
额定电压(Rated voltage)                              [V] / / /
额定电流(Rated current)                              [A] / / /
额定连接容量(Rated connection capacity) (solid/stranded) [AWG] /
额定扭矩(Rated torque)                            [Lb. in] /
通用数据(General data) /
剥线长度(Stripping length)                             [mm] /
螺丝(Screw) /
阻燃等级(Inflammability class)UL94 V-0
环境温度(Ambient temperature)                        [℃] -40~+105
相对湿度(Relative humidity) 5%-95%
抽样检验标准(Inspection standard) MIL-STD-105E   II
允收水准(AQL) 0.65
保质期(Warranty) 12   months
材质和电镀(Material and plating) /
绝缘材质(Housing) PA66
载流体(Current carrier) Copper alloy,Sn plated铜合金,镀锡
