| 目(Item) | 数据(Data) | ||
| 认证(APPROVAL) | / | ||
| 测试标准(Test standard) | IEC60998-1 / UL1059 | ||
| 产品间距(Pitch)[mm] | 5.0 | ||
| 极数(Poles) | 1-18P | ||
| IEC60998-1测试数据（IEC60998-1 Test data) | / | ||
| 额定电压(Rated insulation voltage)[V] | 250 | ||
| 额定电流(Rated current) [A] | 4 | ||
| 额定连接容量(Rated connection capacity)(solid/stranded)[mm²] | 0.5 | ||
| 过压类别/污染等级/绝缘材料组别 (Surge voltage category/pollution degree/material group) |
III/2/III | ||
| 工频耐压(Withstanding Voltage) [KV/min] | 2.0 | ||
| 额定扭矩(Rated torque) [N.m] | / | ||
| UL1059测试数据（UL1059Test data) | UL1059 | ||
| 应用组别(Use group) | B | C | D |
| 电压(Voltage) [V] | 300 | / | / |
| 电流(Current) [A] | 2 | / | / |
| 额定连接容量(Rated connection capacity) (solid/stranded) [AWG] | / | ||
| 额定扭矩（Rated torque） [Lb. in] | / | ||
| 通用数据(General data) | / | ||
| 螺丝(Screw) | / | ||
| 阻燃等级(Inflammability class)UL94 | V-0 | ||
| 环境温度(Ambient temperature) [℃] | -40~+125 | ||
| 相对湿度(Relative humidity) | 5%-95% | ||
| 抽样检验标准(Inspection standard） | MIL-STD-105E II | ||
| 允收水准(AQL) | 0.65 | ||
| 保质期(Warranty) | 12 months | ||
| 材质和电镀 | / | ||
| 绝缘材质(Housing) | PC | ||
| 触点材料(Contact) | Copper alloy ，Sn plated铜合金，镀锡 | ||
